Spin welding machine RSW

  • Home
  • >
  • Plastics
  • >
  • Products
  • Spin welding machine RSW

RSW – Dual servo spin welding machines for thermoplastics

Our range of RSW machines (spin welders) has been designed to meet the most demanding specifications:

  • Accurate angular orientation and collapse distance
  • Reduction of cycle time
  • Repeatability of welds

We fulfill those criteria with a dual servo welder.

Spin welding machine RSW - SONIMAT

Download the full RSW brochure with technical characteristics.

Guaranteed quality

  • Spin welding technology
  • Robust mechanical design
  • Precision of the electric axis
  • High accuracy of the rotary drive
  • Designed, assembled and controlled by our staff
RSW-machine-de-soudure-par-rotation - SONIMAT

Browse the tabs below to explore in detail our RSW spin welding machine.

  • Characteristics
  • Integration
  • Toolings
  • Turnkey solution

Characteristics

  • Perfect mastery of stopping values
  • Repeatability of the process
  • Mastery of penetration speed
  • Optimised productivity gain
  • Column availabable as stand alone with connection and eletrical box

EXCLUSIVE Up to 450mm stroke for greater versatility and easy loading/unloading of even more complex assemblies.

Weldable materials :
POM | PPA | PE | PP | PS | PBT | PA | ABS

RSW - machine de soudure par rotation SONIMAT
null
<p style='text-align: left;'><strong>Interface</strong><br /> • Intuitive programming<br /> • Displays of weld curves<br /> • Recovery of production data</p> <p>
null
<strong>Integrated management of tooling</strong><br /> • Tooling kinematics<br /> • Dual sensor control<br /> • Pneumatic closet included
null
</p> <p style='text-align: left;'><strong>Mechanical design</strong><br /> • ± 0.01 mm accuracy of Z-axis position<br /> • ± 0.1 degree rotation accuracy<br /> • Column rigidity</p> <p>
null
</p> <p style='text-align: left;'>Open chassis for small and large pieces accessibility</p> <p>
null
</p> <p style='text-align: left;'><strong>Mobile protection screen</strong><br /> • Fast opening / closing via electrical control<br /> • 3 transparent sides and sensitive edges</p> <p>

Integration

Integrability on modern automated production lines

Our machines have been designed to work as stand-alone stations, or to be integrated on automatic assembly lines with a robot in front to load / unload  components. Ergonomics and operator safety concepts are more than fulfilled.

Toolings

SONIMAT designs and manufactures the specific tooling for your machine.

  • Engineering office : Engineering, assembly, development of your specific tools
  • Standard clamping module
  • Design without mechanical stop
  • Ergonomic design to facilitate : Production, maintenance and access to tools
Outillage-ultrasons-SONIMAT

Click here to learn more about ultrasonics tools

Turnkey solution

Preliminary project

Expertise
Co-development
Feasibility
Prototype

Manufacturing

Design – Engineering
Mechanical
Assembly
Automatism

On site

Installation
Training
After sales services

Video applications

DOWNLOAD BROCHURES

Would you like to know more about the spin welding machine? Download our dedicated brochures!
